625 SMC Supermoto
Engine
Engine
|
 |
|
Engine |
single-cylinder
4-stroke engine |
|
Displacement (cc) |
625 |
| Bore
/ stroke (mm) |
101 / 78 (3.98 x
3.07") |
|
Performance (homologated) |
21 kW / 6000 rpm |
| Max.
torque |
41 Nm / 3250 rpm |
|
Compression ratio |
11.7:1 |
|
Starter |
E-starter and
kickstarter |
|
Transmission |
5 gears, dog-clutch
engagement |
|
Carburetor |
Keihin MX FCR 41 |
|
Control |
4 valves / OHC,
roller rocker lever |
|
Lubrication |
Pressure lubrication
with 2 Eaton pumps |
|
Engine oil |
Motorex Power Synt
4T 10W50 |
|
Primary drive |
31:79 |
| Final
drive |
X-Ring chain 5/8 x
1/4" |
|
Cooling |
liquid-cooled |
|
Clutch |
wet multi-disc
clutch, operated hydraulically |
|
Ignition |
Kokusan DC-CDI |
|
Chassis
Chassis
|
|
|
| Frame
|
chromium-molybdenum,
power-coated |
|
Subframe |
chromium-molybdenum,
power-coated |
|
Handlebar |
aluminum, conified |
| Front
suspension |
WP-USD 48 mm (1.89") |
| Rear
suspension |
WP - Monoshock |
|
Suspension travel front/rear |
275 / 260 mm
(10.83/10.24") |
| Front
brake |
Brembo 4-piston
floating caliper, 320 mm disc (12.6") |
| Rear
brake |
Brembo 1-piston
floating caliper, 220 mm disc (8.66") |
| Rims,
front/rear |
3.5 x 17" / 5.0 x
17" |
|
Tires, front/rear |
120/70-17";
160/60-17" |
|
Transmission ratio |
17:40 |
|
Battery |
12 V 8.6 Ah |
| Main
silencer |
aluminum |
|
Steering head angle |
63° |
| Wheel
caster |
99 mm (3.9") |
|
Wheelbase |
1510±10mm
(59.45±0.39") |
|
Ground clearance (unloaded) |
280 mm (11.02") |
| Seat
height |
910 mm (35.83") |
| Fuel
capacity |
approx. 9.2 liters /
2.5 liters reserve (2.43/0.66 gal) |
|
Weight (no fuel) |
approx. 146 kg
(321.9 lbs) |
|
|
